INSTALLATION

EASY TO FIT

Fitting our guards is a simple process, by following the instructions and a few tools, a flat head screwdriver, small hammer and trim removal tool, you'll fit them in 30 minutes. If you have remote reservoir shocks a small hole and slit may be required to accommodate the hose.


To install the clips you’ll only require moderate force, if they need a little more persuasion use a small hammer with a gentle tap.


TRICKY HOLES

Occasionally a hole can be a little tricky to fit a clip or the hole is too big, this can happen if a previous owner has drilled out the clips holes, you may need to purchase a slightly smaller or bigger clip to suit that particular hole. There may be small vehicle variations that we cannot foresee, this is not an exact science.


PUSH CLIP FITMENT

It is important to pull the 8mm clips apart before fitting them into the guard.

- Push the back section into the guard

- Locate the body and chassis holes and position into place

- Push the centre clip into the middle of the clip to secure


INSTALLATION INSTRUCTIONS

Please download the appropriate pdf document below for further installation information:

01-Prado150-FJCruiser(4)-INSTALL-Jun25 (pdf)Download
02-Prado150-FJCruiser(2)-INSTALL-Jun25 (pdf)Download
03-HiluxN70(2)-INSTALL-Jun25 (pdf)Download
04-Prado120(2)-INSTALL-Jun25 (pdf)Download
05-LandCruiser70-INSTALL-May25 (pdf)Download
06-PatrolGU-Y61-INSTALL-May25 (pdf)Download
